TGD 80/1-220/35 EMMEVI - FERGAS 164001 Cross-flow fan with double blower for pellet stoves. Specific for high temperatures, it is a quiet, small and very reliable product.
Equivalent to the following EMMEVI-FERGAS cross-flow fans C00110 - 164003
EDILKAMIN ref. 288900 mod. Pellbox SCF
The 80 mm rotor create a swirling motion that generate an output air flow that is stable and uniform. Flow range 660 m³/h.
It uses 120 Watt at full power.
Characteristics | |
Weight (kg) | 2.0000 |
Country of Manufacture | Sweden |
Dimension Depth (mm) | 132 |
Dimension Height (mm) | 105 |
Warranty | 6 months |
MPN | 14706067 |
Electric power supply (V/Hz) | 220-240/ 50-60 |
Power consumption (W) | 120 |
Type | Tangential fan |
Total length [mm] | 579 |
Maximum airflow rate (m³/h) | 660 |
Magnetic core (mm) | 35 |
Fan diameter (mm) | 80 |
Fan length | 220+220 mm |
Nozzle dimensions (mm) | 2 x 230 x 44 |
Compatibility | Edilkamin |
