Circulation pump Grundfos ALPHA2 25-40 180, head 4 m, flow 2.5 m³/h

Pump for heating systems, constant or variable flow systems, hot water recirculation, etc.

  • Stock: In Stock
  • Brand: Grundfos
  • SKU: 08.320.023
£261.18
Excl. VAT

*Products are shipped from Europe. The customer must pay any applicable VAT and customs duties.

    Save 5%   with bank transfer.

Estimated delivery
02.Jul.2025
DHL Schenker
See Shipping Policy

Free return
​60 daysSee details

We accept payments
    See details

The Grundfos ALPHA2 25-40 180 circulation pump has a connection size of 1 1/2", a head of 4 m and a maximum flow rate of 2.5 m³/h.

It can be used in various installations such as - heating systems, constant or variable flow systems, one-pipe or two-pipe systems, hot water recirculation, systems where night mode and energy efficiency are required, refrigeration and air conditioning installations, etc.

There is an AUTOADAPT function for combined heating systems, automatic night mode and summer mode, which ensures pump operation at minimum speed.



Technical parameters:

  • Flow rate: 2.5 m³/h
  • Effort: 4 m
  • Inlet/outlet diameter: 1 1/2"
  • Max. pressure: 10 bar
  • Supply voltage: 230 V
  • Protection level: X4D
  • Temperature range: up to 110°C
  • Weight: 2 kg

Characteristics
Weight (kg) 2.01
Country of Manufacture Denmark
Warranty 2 Years
Operating pressure (bar) Max 10
Temperature range +2°C до +110°C
Electric power supply (V/Hz) 220/ 50-60
Power consumption (W) 18
Rate of flow up to 2.4 m³/h
Media temperature 0°C до +40°C
Power supply [V] 1x230V+/-10% – 50/60 Hz
Insulation class F
Type 25-40 180
