Circulation pump Grundfos ALPHA1 25-60 180, head 6 m, flow 2.28 m³/h, power 45W

Pump for domestic, commercial or industrial heating systems with protection class X4D

  • Stock: In Stock
  • Brand: Grundfos
  • SKU: 08.320.007
£118.28
Excl. VAT

*Products are shipped from Europe. The customer must pay any applicable VAT and customs duties.

    Save 2%   with bank transfer.

Estimated delivery
30.Dec.2025
DHL Schenker
See Shipping Policy

365 DAY RETURN
​365 daysSee details

SECURE PAYMENTS
    See details

The Grundfos ALPHA1 25-60 180 circulation pump has a connection size of 1 1/2", a head of 6 m and a maximum flow rate of 2 m³/h.

It has a protection degree of X4D and a maximum working pressure of 10 bar.

It is suitable for domestic or industrial heating systems with radiators, underfloor heating, for one-pipe and two-pipe systems, etc.

The pump housing is made of cast iron and is coated with a galvanized layer for additional corrosion resistance.

It is equipped with intelligent control and offers constant pressure and proportional pressure modes, as well as fixed performance curves, ensuring optimal operation across a wide range of installations.

The tool-free electrical plug enables quick and easy installation, while the automatic air venting function and dry-running protection ensure quiet and reliable operation.

Thanks to its robust design and ceramic bearings, the pump provides a long service life and requires minimal maintenance.



Technical parameters:

  • Flow rate: 2.28 m³/h
  • Effort: 6 m
  • Inlet/outlet diameter: 1 1/2"
  • Max. pressure: 10 bar
  • Supply voltage: 220-240 V
  • Protection level: X4D
  • Temperature range: -10 up to 110°C
  • Weight: 2.17 kg

Characteristics
Weight (kg) 2.17
Country of Manufacture Serbia
Warranty 2 Years
Operating pressure (bar) Max 10
Temperature range -10°C to +110°C
Electric power supply (V/Hz) 220-240 V-50/60Hz
Power consumption (W) 4-45
Rate of flow up to 2.28 m³/h
Media temperature 0°C to +55°C
Power supply [V] 1 x 220-240 V – 50/60 Hz
Insulation class F
Type 25-60 180
Type File Information
User manual_Grundfos_Alpha2.pdf 2.61MB
